Inclined Liquid Column Manometers
Inclined Liquid Column Manometers
Inclined Liquid Column Manometers
Inclined Liquid Column Manometers
TX Series

Inclined Liquid Column Manometers

Inquiry

Kimo's TX range of inclined liquid column manometers measure slight variations in pressure, depression or differential pressure. They are recommended for measuring overpressures and depressions in clean rooms, operating blocks, laboratories, aseptic rooms, laminar flows etc.

Technical specification table Operation Manual (Simplified Version)
Scale with centered zero
Possibility for measuring positive and negative pressures
High measurement sensitivity and very low pressure ranges
Zero adjusting by moving the slide strip and integrated spirit level for adjusting horizontality


×

Product info

>Kit content

Accessories

Compliance

TX 25

  • Differential pressure
    2,5-0-2,5 mmCE
  • Differential pressure
    25-0-25 Pa

TX 50

  • Differential pressure
    5-0-5 mmCE
  • Differential pressure
    50-0-50 Pa

TX 75

  • Differential pressure
    7,5-0-7,5 mmCE
  • Differential pressure
    75-0-75 Pa

TECHNICAL DETAILS

  • Parameters
    Differential pressure
  • Manometer type
    Inclined liquid column manometer
  • Manometric liquid
    AWS 10 red oil, density 0.87 at 15°C
  • Maximum static pressure
    6 bars
  • Reservoir capacity
    20 ml
  • Wall-mounted
    With or without white PVC support


OPERATING TEMPERATURE

  • Min
    -30.00 °C
  • Max
    60.00 °C



1 white PVC support
2 screws
2 rawlplugs
2 x 487 connectors
1 bottle of AWS.10 liquid
