Si-CA 130

Comprehensive, versatile analyser with touch-screen display

Inquiry

The Si-CA 130 features a touch-screen display and comes with PC-based management software (in addition to the smartphone app) for more in-depth combustion gas analysis. The three field-replaceable cells and sensors offer expanded measurement capability.

Technical specification table Operation manual Operation Manual (Simplified Version)
Field replaceable precalibrated sensors
Large color touch screen
CO sensor measurement up to 8000 ppm
Data management with automatic logging & report creation trough app/PC software
Lightweight, only 350 g (12 oz)
Up to three gas sensors O2, CO and NO or Low NO (for NOx)


×

Product info

Probe

>Kit content

Accessories

APPSoftware

Download

Compliance

Technical documentation

MEASURE DETAILS

  • Units
    °C, %, ppm, m/s, mbar



MEASURING RANGES

  • O2
    0.00 % ... 25.00 %
  • CO
    0.00 ppm ... 8000.00 ppm
  • CO2
    0.00 % ... 99.90 %
  • NO (optional)
    0.00 ppm ... 5000.00 ppm
  • Low NO
    0.00 ppm ... 300.00 ppm
  • NOx (optional)
    0.00 ppm ... 7500.00 ppm
  • Low NOx
    0.00 ppm ... 450.00 ppm
  • Flue temperature
    -20.00 °C ... 1250.00 °C
  • Air temperature
    -20.00 °C ... 120.00 °C
  • Differential temperature
    0.00 °C ... 1250.00 °C
  • Pressure/Draft
    -200.00 mbar ... 200.00 mbar
  • High accuracy draft
    500.00 Pa ... 500.00 Pa
  • Excess air
    0.00 % ... 999.00 %
  • Efficiency
    0.00 % ... 100.00 %
  • Efficiency (condensation)
    0.00 % ... 125.00 %
  • Stack Gas velocity
    0.00 m/s ... 99.00 m/s

TECHNICAL DETAILS

  • Parameters
    CO
    CO₂
    NO
    NO₂
    O₂
  • Displays
    Color graphical display
  • IP Protection
    IP 42
  • Battery life
    8 hours
  • Standards
    2015/863 EU (RoHS 3)
    TÜV SÜD Certification
    UKCA
    NF EN 50379-1
    NF EN 50379-2
    2014/53/EU RED
  • Wireless connection
    1
  • Power supply
    Rechargeable battery, Li-Ion 5100 mA/h 3.6 V
  • Usb
    Yes
  • Sensors
    CO
    CO2
    NOx
    NO
    O2
  • Auto zero
    Yes
  • Printer
    Remote
  • Sensor protection
    Sensor protection by pump stopping
  • Mobile application
    Yes


INSTRUMENT DIMENSIONS

  • Length
    99 mm
  • Width
    49 mm
  • Height
    194 mm
  • Weight
    350 g



OPERATING TEMPERATURE

  • Min
    -5.00 °C
  • Max
    45.00 °C

STORAGE TEMPERATURE

  • Min
    -20.00 °C
  • Max
    50.00 °C



Si-CA 030/130/230 Flexible probe

Si-CA 030/130/230 Flexible probe
Draft probe

Draft probe
Probes 27532, 27533, 27534

Probes 27532, 27533, 27534
1 Si-CA 130 analyzer
1 O2 gas sensors
1 CO gas sensors
1 NO gas sensors
1 Low NO gas sensors
1 Protective rubber holster
1 Flue gas probe with dual hose
1 Water trap with filter
1 AC power supply / charger
1 USB cable
1 Mobile app & PC software
1 Internal wireless communication module
1 Carrying case
1 Quick Start Guide
1 Calibration certificate


Gas leak probe

Gas leak probe
Remote wireless printer

Remote wireless printer
Hose extension

Hose extension
Differential pressure hose kit

Differential pressure hose kit
SCU (Sample Conditioning Unit)

SCU (Sample Conditioning Unit)
NO or Low NO sensor for NOx

NO or Low NO sensor for NOx
Sauermann Control mobile App

Sauermann Control mobile App
Sauermann Control software

Sauermann Control software
